20 Ton Forklift Lifted Diesel Trucks

Hình ảnh lớn : 20 Ton Forklift Lifted Diesel Trucks

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	SINOMTP
Chứng nhận:	ISO/CCC/BV
Model Number:	XG520L

Thanh toán:

Minimum Order Quantity:	1
Giá bán:	Negotiation
Packaging Details:	Nude, but with wax sprayed.
Delivery Time:	25 working days after received payment
Supply Ability:	500 units per month

Tiếp xúc

Chi tiết sản phẩm

Model:	XG520L	Rated lifting capacity:	20000kg
Minimum Turning Radius:	5800mm	Overall Dimensions:	7640x3020x3600mm
Load Center Distance:	900mm	Minimum Ground Clearance:	250mm
Điểm nổi bật:	forklift loading truck , forklift lift truck

Specification:

Product Model	XG520L	Fully-loaded Lifting Speed(mm/s)	180
Rated Lifting Capacity(kg)	20000	Maximum Lifting Height(mm)	3300
Weight (kg)	26000	Minimum Ground Clearance(mm)	250
Minimum Turning Radius (mm)	5800	Track (Front/rear)(mm)	2200/2390
Overall Dimensions:(LxBxH )(mm)	7640x3020x3600	Wheelbase(mm)	4000
Travel Speed: Forward 1-2/Backward(km/h)	12-25/12	Front tyre	4-14.00-24-24PR
Maximum Gradeability (%)	15	Rear tyre	2-14.00-24-24PR
Load Center Distance(mm)	900	Engine model	D6114ZG30B
Tilt Angle of Mast (°)	6°/12°	Engine Rated Power/ Speed (kw/r • p • m)	132/2000
Tilt Angle of Mast (°)	6°/12°	Engine Max. Torque Speed (N • m/r • p • m)	810/1600

Description :

An ideal operation friendly in the engineering and industrial sectors. Adopt loader components for facilitating the maintenance.

Application:

Our forklift truck is especially suitable for places with bad environment and high-intensity work. Currently it is widely used in the port, wharf, industrial and mining enterprises, stations, warehouses, construction sites, and log yards.

Advantage :

1. High power, large torque, low oil consumption

2. Flexible, reliable and convenient steering

3. Safe and reliable brake

4. Strengthened gantry and fork for high durability

5. Adopt loader components to facilitate the maintenance.
