Product Name: | Mining Dump truck | Application: | Transportation |
---|---|---|---|
Horse power: | 336 HP | Drive type: | 6X4 |
Gross Weight: | 48 tons | Cargo body(CBM): | 19 |
Điểm nổi bật: | commercial dump trucks,sinotruk dump truck |
Rated load 30 tons Off road Mining Dump Truck Tipper 336hp with 19m3 body cargo Volume
Specifications:
Model | MT48 |
---|---|
Curb Weight (kg) | 17500 |
Gross Weight (kg) | 48000 |
Rated Load (kg) | 30500 |
Body Volume (m³) | 19 |
Dimension (L×W×H) (mm) | 8775×2558×3760 |
Wheelbase (mm) | 4000+1400 |
Drive Mode | 6×4 |
Max. Speed (km/h) | 65 |
Max. Gradeability (%) | 35 |
Engine | WP10.340E32 |
Rated Power (kW) | 250 |
Transmission | 9JSD150A |
Tire | 12.00R20 |
Axle bearing capacity (t) | 9.5+16+16 |
Axle Ratio | 6.733 |
Description:
1. Reinforced riveted frame with large cross section, and suspension system strengthened, whole machine more reliable.
2. Offset drive’s cab in frame structure, air suspension seat, sealing, safety and comfort improved as a result.
3. Split type 3-stage oil bath air filter applied to deal with tough mining working environment.
4. Drivetrain system optimally matched, large power output but low fuel consumption.
5. Oil temperature drops by 50% by converging Hoisting flow and steering flow, and failure rates of the hydraulic system decreases significantly as a result.
Competitive Advantage
1, The price is competitive; we are the direct channel to supply the mining dump truck
2, Powerful engine and strong frame, which can suit to all kinds of road conditions, especially for the tough roads
3, Fast production period, and quick arrangement of delivery.
4. Professional Sales Team of trucks. Our target is not selling trucks; we help customers choose the best suitable trucks as per customer’s situation.
5, Customization service, as per your request, we will customize our production for you
