Thông tin chi tiết sản phẩm:
Thanh toán:
|
| Production: | Vertical Roller Mill | Wheel diameter: | 1700mm |
|---|---|---|---|
| Output: | 18-48 th | Finish fineness: | 170-14 μm |
| Finish fineness Mesh: | 80-400 | End product moisture: | ≤1% |
| Điểm nổi bật: | crushing stone machine,rock crushing machines |
||
1700mm Mining Vertical Roller Mill 170-14 μm Finish Fineness For Grinding
Specification:
| Production | Vertical Roller Mill |
| Wheel diameter(mm) | 1700 |
| Output (th) | 18-48 |
| Finish fineness μm | 170-40 |
| Finish fineness Mesh | 80-400 |
| End product moisture (%) | ≤1% |
| Grinding material particle size D80 (mm) | <10 |
| Grinding material max feed size(mm) | <42 |
| Moisture of grinding material not to dry (%) | <4% |
| Moisture of grinding material need to dry (%) | 4~15% |
| Into mill air temperature (℃) | <350 |
| Out of the mill air temperature (℃)) | 70~95 |
| Main motor power (kw) | 400 |
Description:
According to customers’ requirements, We success in absorbing foreign experience and world-advanced technology, and in producing our vertical products, with self-owned intellectual property right. Now it has wide application in metallurgy, construction, chemical and mining industries, being the preferred equipment in grinding industry.
Advantage:
1.Small occupation area Low investment cost
2.Low operation cost and long service life
3. High grinding efficiency
4. Excellent drying function
5. Good final products quality
6. Easy to maintain
7. Environmentally friendly
8. High classifying capacity
