HBXG SD6Glgp bulldozer of Caterpillar with 4m³ dozing capacity 1900rpm rated revolution

Hình ảnh lớn : HBXG SD6Glgp bulldozer of Caterpillar with 4m³ dozing capacity 1900rpm rated revolution

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	HBXG
Chứng nhận:	ISO/CCC/BV
Model Number:	SD6Glgp

Thanh toán:

Minimum Order Quantity:	1
Giá bán:	Negotiation
Packaging Details:	Nude
Delivery Time:	30 work days
Supply Ability:	100 units/month

Tiếp xúc

Chi tiết sản phẩm

Type:	LPG	Model:	SD6G(LPG)
Overall dimensions:	5212X3770X3192 mm	Flywheel power:	119 kw
Max.torque:	810/1400 N.m/rpm
Điểm nổi bật:	dozer construction equipment , heavy equipment bulldozer

HBXG SD6Glgp bulldozer of Caterpillar with 4m³ dozing capacity 1900rpm rated revolution

Specifications
Dozer		LGP Tilt
Operation weight		17300 kg
Ground pressure		32.45kpa
Track gauge		2110 mm
Min.ground clearance		445 mm
Gradient		30°/25°
Dozing capacity		4.0 m³
Blade width		3770 mm
Max.digging depth		592 mm
Overall dimensions		5212X3770X3192 mm
Engine
Type		Shangchai SC11CB184G2B1
Rated revolution		1900 rpm
Flywheel power		119 kw
Max.torque		810/1400 N.m/rpm
Rated fuel consumption		≤215 g/kw.h
Undercarriage system
Type		Swing type of sprayed beam. Suspended structure of equalizer bar.
Number of track rollers		7 (each side)
Number of carrier rollers		2 (each side)
Pitch		202.8 mm
Width of shoe		930 mm
Gear	1st	2nd	3rd
Forward km/h	0-4	0-6.9	0-10.8
Backward km/h	0-4.8	0-8.4	0-12.9
Implement hydraulic system
Max.system pressure		15.5 mpa
Pump type		Gears pump
System output		167 L/min
Driving system
Torque converter		Hydraulic mechanical torque convertor with external power split
Transmission		Planetary, power shift transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted.
Steering clutch		Multiple-disc oil power metallurgy disc compressed by spring, hydraulic operated
Steering brake		Brake is oil two direction floating band brake operated by mechanical foot pedal
Final drive		The final drive are double redution with spur gear and segment sprocket.

Description:

SD6G bulldozer is characterized by optimized structure, open view, easy operating and service, reliable entire quality.

Applications:

It can equipped with three shanks ripper, U-blade. It is an ideal machine used in communication, desert, oil field, power, mining etc large earth moving program.

Competitive advantage:

The equalizer bar utilizes free lubricating structure to decrease service cost.
The final drive also untilizes the structure that its bearing clearance is free of adjustment, which is convenient for service.
Braking system untilizes hydraulic boosting structure, which is vonvenient and labor-saving.

HBXG SD6Glgp bulldozer of Caterpillar with 4m³ dozing capacity 1900rpm rated revolution
