Sinomtp Gravity Separation Equipment Spiral Chute 900, 675mm Screw Pitch

Hình ảnh lớn : Sinomtp Gravity Separation Equipment Spiral Chute 900, 675mm Screw Pitch

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	SINOMTP
Chứng nhận:	ISO/CCC
Model Number:	BLL-1500

Thanh toán:

Minimum Order Quantity:	1
Giá bán:	Negotiation
Packaging Details:	Nude
Delivery Time:	30 work days
Supply Ability:	100 units/month

Tiếp xúc

Chi tiết sản phẩm

Type:	Gravity Separation Equipment Spiral Chute	Model:	BLL-1500
Weight (kg):	850/800	Capacity (t/h):	6~8
Feed Density (%):	30 ~55	Feed Size (mm):	0.8 ~0.037
Max. Screw Numbers Per Set:	4	Lateral Dip Angle (degree):	9°
Điểm nổi bật:	mining industry equipment , construction mining equipment

Sinomtp Gravity Separation Equipment Spiral Chute 900, 675mm Screw Pitch

Specification:

Model		BLL-1500
Outside Diameter (mm)		1500
Screw Pitch (mm)		900, 675
Pitch Diameter Ratio		0.48, 0.36
Lateral Dip Angle (degree)		9°
Max. Screw Numbers Per Set		4
Feed Size (mm)		0.8 ~0.037
Feed Density (%)		30 ~55
Capacity (t/h)		6~8
Overall Dimension	Length (mm)	1600
	Width (mm)	1600
	Height (mm)	5300
Weight (kg)		850/800

Description:

A gravity separation equipment of separation different weight mineral by inertial centrifugal force pulp produced in helix turning motion.There are 3 kinds of chute for user to choose, glass steel chute, wear-resistant rubber liner, polyurethane rubber liner.

Work Principle:

Ore pulps are uniformly fed into machine and form different layers as they pass across chute. Heavy minerals precipitate to bottom and are moved toward inner edge by the comprehensive action of various forces; light minerals are moved toward outer inner due to the speedy rotation. As a result, mineral particles with different density are divided into three zones------concentrate, middling and tailing.

Advantage:

1. Stable, easy control, wide range of concentration

2. Large capacity, enrichment ratio, high recovery rate

3. Small cover space, less water consumption, simple structure, no need of power

4. Simple installation, convenient operation,less investment, quick return

Sinomtp Gravity Separation Equipment Spiral Chute 900, 675mm Screw Pitch
