Sinomtp Gravity Separation Equipment Spiral Chute 675, 540, 405mm Screw Pitch

Hình ảnh lớn : Sinomtp Gravity Separation Equipment Spiral Chute 675, 540, 405mm Screw Pitch

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	SINOMTP
Chứng nhận:	ISO/CCC
Model Number:	BLL-900

Thanh toán:

Minimum Order Quantity:	1
Giá bán:	Negotiation
Packaging Details:	Nude
Delivery Time:	30 work days
Supply Ability:	100 units/month

Tiếp xúc

Chi tiết sản phẩm

Type:	Gravity Separation Equipment Spiral Chute	Model:	BLL-900
Weight (kg):	450/400/350	Length (mm):	1060
Width (mm):	1060	Height (mm):	4000
Capacity (t/h):	2~3	Feed Density (%):	25 ~55
Điểm nổi bật:	mining industry equipment , construction mining equipment

Sinomtp Gravity Separation Equipment Spiral Chute 675, 540, 405mm Screw Pitch

Specification:

Model		BLL-900
Outside Diameter (mm)		900
Screw Pitch (mm)		675, 540, 405
Pitch Diameter Ratio		0.75, 0.6, 0.45
Lateral Dip Angle (degree)		9°
Max. Screw Numbers Per Set		4
Feed Size (mm)		0.3 ~0.03
Feed Density (%)		25 ~55
Capacity (t/h)		2~3
Overall Dimension	Length (mm)	1060
	Width (mm)	1060
	Height (mm)	4000
Weight (kg)		450/400/350

Description:

A gravity separation equipment of separation different weight mineral by inertial centrifugal force pulp produced in helix turning motion.There are 3 kinds of chute for user to choose, glass steel chute, wear-resistant rubber liner, polyurethane rubber liner.

Work Principle:

Ore pulps are uniformly fed into machine and form different layers as they pass across chute. Heavy minerals precipitate to bottom and are moved toward inner edge by the comprehensive action of various forces; light minerals are moved toward outer inner due to the speedy rotation. As a result, mineral particles with different density are divided into three zones------concentrate, middling and tailing.
